基于银合金先导润湿的铜磷钎料钎焊钢分析

龙伟民, 董博文, 张青科, 何鹏, 薛鹏

龙伟民, 董博文, 张青科, 何鹏, 薛鹏. 基于银合金先导润湿的铜磷钎料钎焊钢分析[J]. 焊接学报, 2017, 38(1): 1-4. DOI: 10.12073/j.hjxb.20170101
引用本文: 龙伟民, 董博文, 张青科, 何鹏, 薛鹏. 基于银合金先导润湿的铜磷钎料钎焊钢分析[J]. 焊接学报, 2017, 38(1): 1-4. DOI: 10.12073/j.hjxb.20170101
shu
LONG Weimin, DONG Bowen, ZHANG Qingke, HE Peng, XUE Peng. Brazing of carbon steel using Cu-P brazing filler metals based on guide wetting of Ag alloys[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2017, 38(1): 1-4. DOI: 10.12073/j.hjxb.20170101
Citation: LONG Weimin, DONG Bowen, ZHANG Qingke, HE Peng, XUE Peng. Brazing of carbon steel using Cu-P brazing filler metals based on guide wetting of Ag alloys[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2017, 38(1): 1-4. DOI: 10.12073/j.hjxb.20170101
shu

基于银合金先导润湿的铜磷钎料钎焊钢分析

  • 1.

    郑州机械研究所 新型钎焊材料与技术国家重点实验室, 郑州 450001

  • 2.

    哈尔滨工业大学 先进焊接与连接国家重点实验室, 哈尔滨 150001

  • 3.

    南京理工大学 材料科学与工程学院, 南京 210094

基金项目: 国家国际科技合作专项资助项目（2015DFA50470）

Brazing of carbon steel using Cu-P brazing filler metals based on guide wetting of Ag alloys

  • 1.

    State Key Laboratory of Advanced Brazing Filler Metals & Technology, Zhengzhou Research Institute of Mechanical Engineering, Zhengzhou 450001, China

  • 2.

    State Key Laboratory of Advanced Welding and Joining, Harbin Institute of Technology, Harbin 150001, China

  • 3.

    School of Materials Science and Engineering, Nanjing University of Science and Technology, Nanjing 210094, China

摘要

    摘要
  • 摘要: 基于低熔点合金先导润湿的原理，设计制备了一种表面覆盖低熔点银合金层的新型铜磷焊片.采用该焊片钎焊45碳钢，分析了界面反应机理及钎焊接头性能，并和使用普通铜磷焊片钎焊的碳钢接头进行了对比.结果表明，表面覆盖的低熔点银合金早于铜磷合金熔化润湿碳钢基体，并形成反应层，铜磷钎料熔化后与银合金层反应熔合，冷却后形成良好的冶金连接；与使用铜磷钎料直接钎焊的接头相比，银合金先导润湿钎焊的铜磷/碳钢界面化合物层厚度明显减小，抗剪强度超过160 MPa，断裂发生在靠近连接界面的钎焊材料内部，接头强韧性显著改善.
    Abstract: Based on guide wetting mechanism of low melting point alloy, a Cu-P brazing sheet coated with low melting point Ag alloy was prepared, the interfacial reaction mechanisms and properties of the 45 steel joint brazed using the sheet were studied and compared with that brazed joint using common Cu-P brazing alloy. The results revealed that the Ag alloy coating melts before melting of the CuP alloy and wets and reacts with the steel substrate firstly; then the Cu-P alloy melts and fuse with the Ag alloy, forms high-quality metallurgical bonding. The interfacial compounds layer at the joint brazed using Ag alloy coated sheet is far thinner than that brazed with common Cu-P alloy. The shear strength is higher than 160 MPa, the joint fracture inside the braze alloy close to the joint interface, and the strength and toughness are obviously improved.
    • HTML全文
    • 参考文献(12)
  • [1] 高峰, Sekulic D P, 钱乙余. 钎焊技术的最新研究进展[J]. 焊接学报, 2003, 24(4):92-96. Gao Feng, Sekulic D P, Qian Yiyu. Latest research progress of brazing and soldering technologies[J]. Transactions of the China Welding Institution, 2003, 24(4):92-96.
    [2] 李红, Tillmann W, 栗卓新, 等. 高品质高可靠性钎料的技术发展及应用[J]. 焊接学报, 2014, 35(4):108-112. Li Hong, Tillmann W,, Li Zhuoxin, et al. Development and application of high quality and high reliability brazing filler materials[J]. Transactions of the China Welding Institution, 2014, 35(4):108-112.
    [3] 鲍丽, 龙伟民, 张冠星, 等. 微量Ca元素对AgCuZn钎料性能的影响[J]. 焊接学报, 2012, 33(12):57-60. Bao Li, Long Weimin, Zhang Guanxing, et al. Effects of trace calcium on performance of AgCuZn alloy[J]. Transactions of the China Welding Institution, 2012, 33(12):57-60.
    [4] 李卓然, 刘彬, 冯吉才. 中温无镉钎料的研究进展[J]. 焊接技术, 2008, 37(6):2-6. Li Zhuoran, Liu Bin, Feng Jicai. Research progress of middle temperature Cd-free brazing filler metal[J]. Welding Technology, 2008, 37(6):2-6.
    [5] 卢方焱, 薛松柏, 赖忠民, 等. 镓对AgCuZn钎料组织和性能的影响[J]. 焊接学报, 2009, 30(1):55-59. Lu Fangyan, Xue Songbai, Lai Zhongmin, et al. Effect of gallium on microstructure and properties of Ag-Cu-Zn filler metal[J]. Transactions of the China Welding Institution, 2009, 30(1):55-59.
    [6] 夏天东, 张倩, 俞伟元. 几种典型Cu-P及Ag-Cu-Zn钎料性能的模糊综合评价[J]. 热加工工艺, 2013, 42(19):212-214. Xia Tiandong, Zhang Qian, Yu Weiyuan. Fuzzy comprehensive evaluation of performance of typical Cu-P and Ag-Cu-Zn alloys[J]. Hot Working Technology, 2013, 42(19):212-214.
    [7] 黄俊兰, 龙伟民, 张冠星. Sn元素对铜磷钎料性能和组织的影响[J]. 焊接, 2012(3):57-60. Huang Junlan, Long Weimin, Zhang Guanxing. Effects of Sn on microstructure and properties of Cu-P series brazing filler metals[J]. Welding & Joining, 2012(3):57-60.
    [8] 龙飞, 胡庆贤, 徐华, 等. 铜磷钎料热拉拔过程加热工艺对钎料组织和塑性的影响[J]. 焊接学报, 2015, 36(9):31-34. Long Fei, Hu Qingxian, Xu Hua, et al. Effect of heating process on microstructure and plasticity of copper-phosphorus brazing filler metal during thermoplastic drawing process[J]. Transactions of the China Welding Institution, 2015, 36(9):31-34.
    [9] 邹家生, 王超, 许祥平, 等. Cu-P基非晶钎料钎焊机理[J]. 焊接学报, 2011, 32(12):33-36. Zou Jiasheng, Wang Chao, Xu Xiangping, et al. Bonding mechanism of brazing of amorphous Cu-P filler metal[J]. Transactions of the China Welding Institution, 2011, 32(12):33-36.
    [10] 韩上海, 张卫红, 潘继民. 铜磷基钎料用于铜与低碳钢钎焊的研究[J]. 郑州工学院学报, 1990, 11(3):143-145. Han Shanghai, Zhang Weihong, Pan Jimin. Brazing copper to mild using copper-phosphorus base brazing foill[J]. Journal of Zhengzhou University of Technology, 1990, 11(3):143-145.
    [11] 李玉龙, 何鹏, 冯吉才, 等. TiAI/40Cr感应钎焊接头界面结构及力学性能分析[J]. 机械工程学报, 2005, 41(10):93-97. Li Yulong, He Peng, Feng Jicai, et al. Research on mechanical properties and microstructures of TiAl/40Cr joint obtained by induction brazing method[J]. Chinese Journal of Mechanical Engineering, 2005, 41(10):93-97.
    [12] 黄杰, 薛松柏, 王博. 合金元素对Cu-P系钎料性能影响的研究现状[J]. 焊接, 2014(11):11-14. Huang Jie, Xue Songbai, Wang Bo. Research status on the effects of alloy elements on properties of Cu-P series brazing filler metals[J]. Welding & Joining, 2014(11):11-14.
