排水罩风场特征及其对焊接电弧影响的数值模拟

高延峰,胡翱

高延峰,胡翱. 排水罩风场特征及其对焊接电弧影响的数值模拟[J]. 焊接学报, 2017, 38(8): 59-62. DOI: 10.12073/j.hjxb.20150827001
引用本文: 高延峰,胡翱. 排水罩风场特征及其对焊接电弧影响的数值模拟[J]. 焊接学报, 2017, 38(8): 59-62. DOI: 10.12073/j.hjxb.20150827001
GAO Yanfeng, HU Ao. Numerical simulation of wind characteristics in local dry welding chamber and its influence on welding arc[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2017, 38(8): 59-62. DOI: 10.12073/j.hjxb.20150827001
Citation: GAO Yanfeng, HU Ao. Numerical simulation of wind characteristics in local dry welding chamber and its influence on welding arc[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2017, 38(8): 59-62. DOI: 10.12073/j.hjxb.20150827001

排水罩风场特征及其对焊接电弧影响的数值模拟

Numerical simulation of wind characteristics in local dry welding chamber and its influence on welding arc

  • 摘要: 水下焊接技术在水下工程建设和修复方面具有大量的应用需求. 在水下焊接方法中,局部干法焊接采用排水罩将焊接区域的水排开进行焊接,接头质量较好,易于实现水下自动化焊接. 然而,局部干法焊接时需要在排水罩内通入高压空气将水排开. 为了研究高压气体在排水罩内形成的风场结构及其对焊接过程和电弧特性的影响,文中采用数值模拟的方法,对排水罩内的湍流气体进行了模拟. 并研究了排水罩内侧向风场对电弧等离子体的温度场、速度场、压力场的影响规律. 发现侧向风场对弧柱中心区以外部分的影响较大,弧柱的吹偏角度与侧向风速基本上呈线性关系. 最后进行了焊接试验,采用高速相机拍摄电弧在不同侧向风速下的形态,发现其实际变化与模拟结果基本一致.
    Abstract: Underwater welding technology has been widely applied in the building and repairing of underwater construction in recent years. In the underwater welding technologies, local dry welding method which adopts local dry chamber to prevent the effect of water on the welding process has some advantageous such as better joint quality and ease to realize automatic welding. However, in the process of local dry welding the highpressure compress air need to be injected into the local dry chamber in order to prevent the water flow into it. In this paper, a numerical simulation method is adopted to study the structure of the wind field in the local dry chamber firstly. Based on the simulation results, the structure of local dry chamber is optimized. And then the impacts of the wind field in the local chamber to the welding process and arc characteristics such as the arc temperatures, velocities and pressures are analyzed. The simulation results show that the lateral wind has a great influence on the welding arc column, and the declination of arc column displays a linear relationship with the increasing of lateral wind speed. Finally, a highspeed camera is used in the welding experiments to photograph the arc shape under different lateral wind. It is found that the experimental results are consistent with the simulation results.
  • [1] 朱加雷, 焦向东, 金 枫, 等. 局部干法自动水下焊接系统的研究[J]. 电焊机, 2009, 39(8): 10-13.Zhu Jialei, Jiao Xiangdong, Jin Feng,etal. Research on local dry automatic under water welding system[J]. Electric Welding Machine, 2009, 39(8): 10-13.[2] 蒋力培, 王中辉, 焦向东, 等. 水下焊接高压空气环境下GTAW电弧特性[J]. 焊接学报, 2007, 28(6): 1-4. Jiang Lipei, Wang Zhonghui, Jiao Xiangdong,etal. Characteristics of GTAW arc in underwater welding under high-pressure air condition[J]. Transactions of the China Welding Institution, 2007, 28(6): 1-4.[3] 梁 明, 王国荣, 钟继光. 采用微型排水罩的药芯焊丝水下焊接焊缝自动跟踪系统[J]. 机械工程学报, 2007, 43(3): 148-153. Liang Ming, Wang Guorong, Zhong Jiguang. Vision-based seam tracking system of the underwater flux-cored arc welding[J]. Chinese Journal of Mechanical Engineering, 2007, 43(3): 148-153.[4] 杜健辉, 石永华, 王国荣, 等. 基于PCA_Nu-SVR的水下焊缝偏差识别方法[J]. 焊接学报, 2011, 32(3): 21-24. Du Jianhui, Shi Yonghua, Wang Guorong,etal. Seam offset identification of underwater arc welding using PCA_Nu-SVR[J]. Transactions of the China Welding Institution, 2011, 32(3): 21-24.[5] Hu J, Tsai H L. Heat and mass transfer in gas metal arc welding. part I: the arc[J]. International Journal of Heat and Mass Transfer, 2007, 50(5): 833-846.[6] Choo R T C, Szekely J, Westhoff R C. On the calculation of the free surface temperature of gas-tungsten-arc weld pools from first principles: part I. modeling the welding arc[J]. Metallurgical Transations B, 1992, 23 (3): 357-369.
