核用SA508-3钢特厚板焊后热处理有限元分析

陈重毅; 麻永林; 王文君; 邢淑清; 陆恒昌

核用SA508-3钢特厚板焊后热处理有限元分析

1.
内蒙古科技大学材料与冶金学院, 包头 014010
2.
包钢西北创业实业有限公司包钢设计研究院, 包头 014010

基金项目: 国家科技重大专项子课题项目(2009ZX04014-064-05)

计量
- 文章访问数: 497
- HTML全文浏览量: 3
- PDF下载量: 253
出版历程
- 收稿日期: 2014-04-24

Finite element analysis on post-weld heat treatment of heavy-section SA508-3 steel plate for nuclear pressure vessel

1.
School of Materials and Metallurgy, Inner Mongolia University of Science and Technology, Baotou 014010, China
2.
Baogang Design & Research Institute, Baogang Northwest Venture Industrial Development Co. Ltd, Baotou 014010, China

摘要

摘要: 为了得到SA508-3钢特厚板焊接残余应力分布及焊后热处理对残余应力分布的影响,利用有限元方法对焊接及焊后热处理进行了模拟计算,计算结果表明:焊后热处理对试板焊接应力分布趋势影响较小,但焊后热处理可以大大减小接头应力数值,其中,纵向应力最大减小幅度为72%,横向应力最大减小幅度为70%;焊接接头存在应力分布准稳定区,且接头内部残余应力水平最小,其次为接头上表面,接头下表面应力水平最大;通过残余应力测定试验与模拟结果比对,两者结果吻合度很高,说明计算模型及计算方法可靠,可以指导实际SA508-3钢特厚板焊后热处理生产.
- 低合金高强钢 /
- 焊后热处理 /
- 有限元法 /
- 残余应力 /
- 试验验证
Abstract: In order to investigate the distribution of welding residual stress in heavy-section SA508-3 steel welded joint and the effect of post-weld heat treatment (PWHT) on distribution of residual stress, the welding and PWHT process was numerically simulated by using finite element method. The simulated results show that PWHT had little effect on the distribution of welding residual stress, but PWHT could significantly reduce the welding residual stress. The maximum amplitude of longitudinal stress decreased by 72%, and the maximum amplitude of transverse stress reduced by 70%. Quasi-stable stress region distributed in the welded joint. The residual stress inside the welded joint was the smallest, followed by that on the upper surface, and the residual stress on the bottom surface of welded joint was the greatest. The simulated residual stress agreed well with the experimental results, indicating that the calculation model and method are reliable and can guide the practical PWHT of SA508-3 steel plates.
- high-strength low-alloy steel /
- post-weld heat treatment /
- finite element method /
- residual stress /
- experimental verification

HTML全文

参考文献(7)

[1]	Spence J, Nash D H. Milestones in pressure vessel technology[J]. Pressure Vessels and Piping, 2004, 81(2): 89-118.
[2]	姜运建, 荆洪阳, 徐连勇, 等. 焊接残余应力对P92钢Ⅳ型蠕变开裂的影响[J]. 焊接学报, 2011, 32(1): 16-20. Jiang Yunjian, Jing Hongyang, Xu Lianyong, et al. Effect of welding residual stress on type IV creep failure of P92 steel[J]. Transactions of the China Welding Institution, 2011, 32(1): 16-20.
[3]	Mark A F, Francis J A, Dai H, et al. On the evolution of local material properties and residual stress in a three-pass SA508 steel weld[J]. Acta Material, 2012, 60(8): 3268-3278.
[4]	Lee Yoon-Sun, Kim Min-Chul, Lee Bong-Sang, et al. Evaluation of microstructure and mechanical properties on post-weld heat treatment in the heat affected zone of SA508 Gr.4N Ni-Mo-Cr low alloy steel for reactor pressure vessel[J]. Journal of the Korean Institute of Metals and Materials, 2009, 47(3): 139-146.
[5]	蒋文春, 王炳英, 巩建鸣. 焊接残余应力在热处理过程中的演变[J]. 焊接学报, 2011, 32(4): 45-48. Jiang Wenchun, Wang Bingying, Gong Jianming. Development of welding residual stress during post-welding heat treatment[J]. Transactions of the China Welding Institution, 2011, 32(4): 45-48.
[6]	迟露鑫, 麻永林. 核电SA508-3钢大型筒体环焊残余应力分析[J]. 焊接学报, 2013, 34(8): 85-88. Chi Luxin, Ma Yonglin. Analysis of residual stresses on large-scale wall pipe circular weld of SA508-3 steel for nuclear power[J]. Transactions of the China Welding Institution, 2013, 34(8): 85-88.
[7]	Dai H, Francis J A, Withers P J. Prediction of residual stress distributions for single weld beads deposited on to SA508 steel including phase transformation effects[J]. Materials Science and Technology, 2010, 26(8): 940-949.
